首頁 / 產品 / Snap-on / WELDIGNREDRACE 新品
WELDIGNREDRACE
Ignite Auto-Darkening Wide-View Welding Helmet with Grind Feature and 360° Light (Red Race) WELD HELMET W/ LIGHT & GRIND
Snap-on 產地 CHN
品牌 Snap-on
料號 WELDIGNREDRACE
原產地 CHN
重量 1.18 kg
Switching Time, light to dark 1/25,000 second
UV/IR Protection Up to Shade DIN 16 at all times
Shade Control Internal, Variable Shade
Low TIG Amps Rated ≥ 2 amps DC and AC
Storage Temperature, °F (°C) -4–158 (-20–70 )
Delay 0.1–1.0 s (5 levels) 原廠資料與完整規格 ↓ 技術資料 詳細規格 相關商品
產品特色PRODUCT DETAILS · 原廠資料 180° viewing area with fixed shade; 10 side lenses and a full outer protective shield create a wide field of vision Fully integrated LED light provides enhanced visibility with 360° pivot and flip-out capability External grind lockout button Extra-large heavy-duty auto-darkening lens with hyper-view technology Solar powered ADF with lithium battery back-up Patented lightweight quick-adjust comfort-fit headgear Sleek, compact shell design for tight work areas 保固WARRANTY · 原廠資料 Mat/Workmanship Snap-on , Blue Point, Consumables, Sets, Service Repair Parts, Private Branded Mfg. by Snap-on & Industrial Specials The item will be Audited at the Replacement Processing Center.
以上原廠資料來源:Snap-on 原廠官網 ↗ 。規格以原廠公告為準,採購前可透過 LINE 向我們確認。
詳細規格SPECIFICATIONS 規格項目 規格值 商品編號 WELDIGNREDRACE 商品名稱 WELD HELMET W/ LIGHT & GRIND 品牌 Snap-on 主題分類 照明設備 交期 請洽詢,由客服依採購需求確認 零售價(含稅) 請洽詢 原產地 CHN 重量 1.18 kg Switching Time, light to dark 原廠 1/25,000 second UV/IR Protection 原廠 Up to Shade DIN 16 at all times Shade Control 原廠 Internal, Variable Shade Low TIG Amps Rated 原廠 ≥ 2 amps DC and AC Storage Temperature, °F (°C) 原廠 -4–158 (-20–70 ) Delay 原廠 0.1–1.0 s (5 levels) Operating Temperature 原廠 14–131 °F (-10–55 °C ) Application Range 原廠 Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Oxyfuel Gas Welding (OFW);Oxygen Cutting OC); Grinding Helmet Material 原廠 High Impact Resistance Nylon Sensitivity Control 原廠 Low–High (5 levels) Grinding 原廠 Yes, dual control (from internal or external) Power On/Off 原廠 Automatic On/Off Special Modes (Smart/Grind) 原廠 — Power Supply 原廠 Solar Cell, battery replaceable (2 x CR2450 lithium battery) Memory 原廠 — Cartridge Size, inches (mm) 原廠 5.63 x 5.08 x 1.42 (143 x 129 x 36) Viewing Area, inches (mm) 原廠 3.74 x 3.23 (95 x 82) LED Light 原廠 Max Work lighting gets 125+/-5 lumen. Continuous run time: 120+/-10 min. Recharging time: approx. 70 min. Battery capacity 3.7 V/500 mAH Smart 原廠 — Variable Shades 原廠 Cutting Shade 5–8; Welding Shade 9–13 Arc Sensors 原廠 4 Grind State 原廠 DIN 4 Applicable Standards 原廠 ANSI® Z87.1 Light State 原廠 DIN 4
