Name: CIRCLIP PLIER 2928-160
Brand: BAHCO
SKU: 2928-160

正在載入商品資料…

2928-160

Internal and External Circlips Resettable Pliers 160 mm

CIRCLIP PLIER 2928-160

BAHCO

Adjustable circlip pliers for both internal and external circlips
Ring diameter: 7-26 mm to 46-102 mm
Eyelet diameter: 3-26 mm to 32-102 mm
Tip diameter: 0.6 mm to 1.8 mm
Circlip tip 90°: 0.9 mm to 3 mm
Circlip tip 15°: 2.3 mm to 3 mm
With interchangeable tips
Patented pliers, equipped with interchangeable tips (straight, 15° and 90°) which can easily be adapted for use with internal or external circlips
5 Pairs of tips are supplied with the -160 and -200 and 6 pairs with the -250
Valid for internal circlips from 8 to 100 mm diameter and for external circlips from 3 to 100 mm
The 2928-160 pliers, which thus covers a range of applications previously embraced by as many as 10 conventional pliers
Regulation stop mechanism for easier use and prevention of damage to circlips due to excessive force

型號	Length A	Head Length	Head Width (mm)	Head Thickness (mm)	Ring diameter	Eyelet diameter	Tip Diameter	Circlip tip 90°	Weight, g
2928-160	160 mm	23.5 mm	21.5 mm	17 mm	7-26 mm	3-26 mm	0.6 0.9 1.2 mm	0.9 1.2 mm	120 g

型號	Length A	Head Length	Head Width (mm)	Head Thickness (mm)	Ring diameter	Eyelet diameter	Tip Diameter	價格
2928-160本商品	160 mm	23.5 mm	21.5 mm	17 mm	7-26 mm	3-26 mm	0.6 0.9 1.2 mm	價格請洽詢
2928-200	200 mm	32 mm	23.5 mm	20 mm	10-51 mm	7-51 mm	0.9 1.2 1.8 mm	價格請洽詢
2928-250	250 mm	36 mm	30 mm	22 mm	46-102 mm	38-102 mm	—	價格請洽詢
