3115
2-Arm Universal Puller with Long Arms/Spindle and Galvanized Finish 80-250 mm
TWO-ARM Puller S100-S3
BAHCO
NT$12,660含稅 · 原廠正品
可訂購· 原廠調貨 · 交期洽 LINE
數量
原廠正品台灣官方授權代理
新北現貨倉48 小時台灣出貨
LINE 技術諮詢平日 09:00–18:00
QUICKBUYTOOLS · TAIWAN AUTHORIZED
產品特色PRODUCT DETAILS · 原廠資料
- Extractor: 2 arms
- Arms always grip parallel to each other
- Arms and yokes are drop-forged
- By reversing the arms, the extractor can be used as internal or external
- The large claw surface offers many advantages for careful and quick removal of pulleys, gears and ball bearings etc.
- Made of special steel
- Galvanised finish, with induction hardened spindle
- External-internal reversible by relocating arms
- Wear-resistant, induction-hardened spindles starting in size C
尺寸示意圖DIMENSIONS · 原廠線稿
| 型號 | Width | Height | Width 2 | Torque range | Maximum loading capacity | Maximum loading capacity | Working width claw | Thickness claw | Length claw | Width claw | Spare spindle type & size | Hexagon size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3115 | 80-250 mm | 300 mm | 160-330 mm | 360 N·m | 11 to | 110 kN | 5 mm | 25 mm | 54 mm | 35 mm | G3/4"x14x360 mm | 27 mm |
詳細規格SPECIFICATIONS
| 規格項目 | 規格值 |
|---|---|
| 商品編號 | 3115 |
| 商品名稱 | TWO-ARM Puller S100-S3 |
| 品牌 | BAHCO |
| 主題分類 | 拆卸與拉拔工具 |
| 狀態 | 可訂購 · 原廠調貨 · 交期洽 LINE |
| 零售價（含稅） | NT$12,660 |
